S355J2W+N / Corten Steel Plates
Weathering structural plate. Copper, chromium and nickel additions let a dense, adherent oxide patina form that seals the surface, so the structure can be left unpainted and the maintenance coating cycle disappears.
- Self-protecting patina removes the painting cycle
- Same 355 MPa yield and -20 C toughness as S355J2+N
- Supplied in the normalised condition for weld consistency
- Profile cut to architectural drawings
Available forms & sizes
| Form | Size range |
|---|---|
| Plates | 5 - 200 mm thk, up to 3000 mm wide, cut to size |
| Sheets & Coils | 2 - 12 mm thk, 1250 / 1500 / 2000 mm wide |
Chemical composition (%)
| Element | Min | Max |
|---|---|---|
| C | - | 0.16 |
| Cu | 0.25 | 0.55 |
| Cr | 0.40 | 0.80 |
| Ni | - | 0.65 |
| Mn | 0.50 | 1.50 |
Mechanical properties
| Property | Value | Unit |
|---|---|---|
| Yield Strength | 355 min (t <= 16 mm) | MPa |
| Tensile Strength | 470 - 630 | MPa |
| Elongation | 20 min | % |
| Impact Energy | 27 J min at -20 C | J |
Physical properties
| Property | Value | Unit |
|---|---|---|
| Density | 7.85 | g/cm3 |
| Modulus of Elasticity | 210 | GPa |
Typical applications
