SA516 Grade 60 Plates
Carbon pressure vessel plate for moderate and lower temperature service. The lower carbon of Grade 60 gives better formability and weldability than Grade 70, which suits cold-formed heads, thin shells and plant where notch toughness matters more than tensile strength.
- Better formability than Grade 70 for cold-formed heads
- Normalised, impact tested and simulated PWHT options
- Dual certification, NACE MR0103 / MR0175 and HIC / SSC testing available
- Ultrasonic examination to SA578 and Z-direction testing on request
Available forms & sizes
| Form | Size range |
|---|---|
| Plates | 5 - 200 mm thk, up to 3000 mm wide, cut to size |
Chemical composition (%)
| Element | Min | Max |
|---|---|---|
| C | - | 0.23 (t <= 25 mm) |
| Mn | 0.60 | 1.20 |
| Si | 0.15 | 0.40 |
| P | - | 0.025 |
| S | - | 0.025 |
Mechanical properties
| Property | Value | Unit |
|---|---|---|
| Yield Strength | 220 min | MPa |
| Tensile Strength | 415 - 550 | MPa |
| Elongation | 21 min (200 mm gauge) | % |
| Condition | As rolled or normalised | - |
Physical properties
| Property | Value | Unit |
|---|---|---|
| Density | 7.85 | g/cm3 |
| Max Service Temperature | 425 | C |
Typical applications
